What it is and what it does
The Siemens 6ES7924-0BD10-0BA0 is a TPRO terminal block with an integrated relay, designed for the SIMATIC S7-1500 I/O system. It provides 8 normally open (NO) output contacts, each rated for AC 230V/3A or DC 30V/3A, switched by a 24V DC coil. The block uses screw terminals for field wiring and includes a per-channel LED for status indication. The 16-pole IDC connector mates to the backplane bus, so this block is a drop-in output module for an S7-1500 station — no separate wiring to the CPU required.
What the ratings mean for fit
The 8 NO contacts at 230V/3A AC or 30V/3A DC cover typical pilot-duty loads: contactor coils, solenoid valves, indicator lamps, and small motor starters. The 3A rating is continuous — not inrush — so for a contactor with a 100 VA inrush coil, the steady-state hold current is well under 3A, but the inrush may exceed it briefly; the relay's make/carry capacity handles that, but verify the specific load's inrush against the relay's make rating. The 24V DC coil is standard for S7-1500 systems, powered directly from the backplane bus. The LED per channel is a practical diagnostic aid during commissioning and fault-finding — you see the output state without a meter.
