Siemens 6GT2191-0BH50

Siemens 6GT2191-0BH50 SIMATIC RF MV Plug-in Cable, 300 V, 4

MPN 6GT2191-0BH50
Active

Siemens SIMATIC RF, MV plug-in cable, pre-assembled, between RF166C, RF170C or RF18xC/CI and MV320; coiled, length 5 m useful length 1.6 to 4 m.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Product details

The Siemens 6GT2191-0BH50 is a pre-assembled spiral communication cable that connects an MV320 read/write head to a SIMATIC RF communication module — specifically the RF166C, RF170C, or RF18xC/CI. It's the plug-in link between the antenna and the controller interface in an RFID identification system. The cable is coiled, giving a working length that stretches from 1.6 m to 4 m, with a total cable length of 5 m. That 1:4 elongation ratio means it retracts when not under tension, keeping the line side tidy. Rated for a maximum of 300 V, this is a signal-level cable — not a power feed. The braided shield of tin-plated copper wires keeps RF noise out of the communication line, which matters when the cable runs alongside motor drives or contactors in the panel.

Connector and Wiring Detail

One end terminates in an M12 male, 8-pin, straight connector; the other end is an RJ-50. That RJ-50 is a 10-position modular plug, not the standard 8-position RJ-45 — verify the communication module's port accepts RJ-50 before wiring. The cable carries 4 electrical cores plus data wires with insulation per DIN 47100. Wire insulation is TPE-E, which holds up to flexing in the spiral. Tensile load is limited to 5.6 N maximum — don't use this as a strain relief or pull cord.

MPN
6GT2191-0BH50
