The Siemens 6GT2398-1DA10 is a stainless steel V2A RFID antenna from the SIMATIC RF200/RF300 family, operating at 13.56 MHz. It's built for industrial washdown zones and outdoor mounting — IP67, M18 x 1 thread, 40 mm depth, with a 3 m PUR trailing cable terminated in an M8 4-pole male connector. The antenna mounts flush to metal surfaces with zero recommended clearance, so no standoff spacer is needed. Shock rated at 500 m/s² and vibration at 200 m/s², it survives on robot arms or conveyor frames.
Integration notes
Compatible with RF250R, RF350R, and RF350M readers — the 13.56 MHz frequency matches HF RFID systems. The M18 x 1 thread and two stainless steel nuts let you panel-mount through a single 18 mm hole. The 3 m cable reaches most reader locations inside a panel; if you need more, the M8 connector breaks out easily. The ATEX approval of the connected reader applies — the antenna itself carries IECEx marking but no standalone ATEX certificate.
