Siemens 6GT2801-1AB20-0AX1

Siemens 6GT2801-1AB20-0AX1 SIMATIC RF300 Reader, IP67, 13.56

MPN 6GT2801-1AB20-0AX1

Siemens SIMATIC RF300 Reader RF310R, RS422 interface, 13.56 MHz, IP67, 55x75x30 mm, mature lifecycle.

$456.29 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6GT2801-1AB20-0AX1 specifications
ParameterValue
IP ratingIP67
Mounting4 x M5 screws
Shock acceleration500 m/s²
Coloranthracite
Depth55 mm
Width75 mm
Height30 mm
MaterialPA 12

Product details

The Siemens 6GT2801-1AB20-0AX1 is a SIMATIC RF300 Reader RF310R running in ISO scan mode, built for serial connection to control systems. It reads RF300-specific and ISO 15693 transponders (MDS Dxxx family) at 13.56 MHz, with a maximum read range of 60 mm — though that range depends on the specific transponder type you pair it with. Communication runs over an RS422 interface at distances up to 1000 m, using protocols that include RF300-specific, ISO 15693, and ISO 18000-3. Typical read access per byte clocks in at 0.13 ms, with a maximum transfer rate of 106 kbit/s over the radio link.

Mounting and environment — what IP67 means here

The housing is PA 12 in anthracite, sealed to IP67. That means the reader body and its M12 8-pin connector withstand washdown, dust, and temporary immersion — suitable for food-and-bev lines, machining coolant splash, or outdoor stations where you'd rather not build a separate enclosure. Mounting is via 4 x M5 screws through the rotated base plate. The footprint is 75 mm wide, 55 mm deep, 30 mm tall — compact enough to tuck into tight machine frames. It's rated for shock resistance per EN 60721-3-7 Class 7 M2, handling 500 m/s² shock and 200 m/s² vibration. That's the kind of spec that matters when the reader is bolted directly to a press or a conveyor frame rather than isolated on a panel door.

Power and wiring

Powered at 24 V DC nominal (20.4 to 28.8 V range), drawing 0.05 A typical at 24 V. The M12 8-pin connector handles both power and RS422 signals in one cable run — keeps the wiring clean and reduces a point of failure compared to separate power and comms cables. The reader is not multitag-capable, so it reads one transponder at a time.

The listed MTBF is 170 years.
