The Siemens 6SL3120-1TE15-0AA3 is a SINAMICS S120 Single Motor Module in booksize format, designed as a spare part for multi-axis drive systems. It accepts a 600 V DC input from a shared DC link and delivers 400 V 3-phase AC output rated at 5 A, with internal air cooling. This module supports optimized pulse patterns and the extended Safety Integrated functions, including DRIVE-CLiQ cable connectivity for direct communication with the control unit.
Listed lifecycle stage is mature. The document date is 06.01.2021, indicating the technical data sheet was current as of that date.
Integration & Deployment
Internal air cooling requires clearance around the module for natural convection; forced ventilation is not needed but ambient temperature must stay within the S120 cabinet design limits. The 5 A output (400 V 3-phase) is sized for a small servo or induction motor — think a 2.2 kW spindle or a compact axis on a pick-and-place line. The DRIVE-CLiQ interface carries both motor feedback and safety signals, so cable routing should avoid high-current power cables to prevent EMC coupling.
