What This Mounting Set Is For
This 6SL3200-0SK04-0AA0 is a small parts mounting set designed for the SINAMICS G120P Power Module PM230 in IP55/UL Type 12 enclosures, frame size FSC, or for IP20 builds. If you are rebuilding a PM230 drive or replacing lost mounting hardware, this kit contains the brackets, screws, and spacers needed to secure the module in the panel. The IP55 variant is common on pump and fan applications where the drive is mounted directly on the motor or in a washdown zone — the mounting set keeps the module properly seated for heat dissipation and vibration resistance.
The set mounts to the Power Module PM230 chassis — frame size FSC — in either IP55/UL Type 12 or IP20 configurations. If you are swapping a drive in the field, verify the frame size on the existing module nameplate; the FSC frame is the mid-size variant in the G120P family, typically covering the 7.5 kW to 15 kW range depending on the voltage variant. The kit does not include the module itself, only the mechanical attachment hardware.
