Siemens 6SL3210-1NE27-5UL0 — AC Drives (VFD)

Siemens 6SL3210-1NE27-5UL0 SINAMICS G120 PM230, 37 kW LO, IP

MPN6SL3210-1NE27-5UL0

Siemens SINAMICS G120 Power Module PM230, unfiltered, IP20, 3AC 380-480 V +10/-10% 47-63 Hz, output low overload 37 kW (110% for 60 s, 100% for 240 s), ambient 0 to +40 °C, 499 x 275 x 204 mm (HxWxD), FSE without control unit and panel, approved for CU240B/E-2 and CU230P-2 firmware V4.4, PM230 does not support safety.

Siemens 6SL3210-1NE27-5UL0 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jul 2026

Specifications

Specifications

6SL3210-1NE27-5UL0 — Specifications
ParameterValue
Datum: 23.06.2021Änderungen vorbehalten © Copyright Siemens 2021

Product details

Power Module PM230 — 37 kW Low Overload, Unfiltered

The Siemens 6SL3210-1NE27-5UL0 is a SINAMICS G120 Power Module PM230 in an unfiltered IP20 enclosure, rated for 37 kW low overload on a 3AC 380-480 V supply. The low-overload duty cycle permits 110 % rated current for 60 s and 100 % for 240 s, which covers most pump, fan, and conveyor profiles without oversizing the drive. Ambient temperature range is 0 to +40 °C for low-overload operation.

Integration Constraints

This power module ships without a Control Unit or operator panel — it requires a CU240B/E-2 or CU230P-2 control unit (firmware V4.4) to function. The PM230 does not support safety functions, so any application requiring Safe Torque Off or similar must use a PM240 or PM240-2 variant. The unfiltered variant is intended for installations where an external line filter handles conducted emissions; verify compliance with the local EMC directive before panel integration.

Frequently asked questions

Where can I buy 6SL3210-1NE27-5UL0 and get a price?

This PM230 is sourced to order against an RFQ through independent distribution. Submit a request for quote to confirm current availability and pricing.

What is the closest alternative to 6SL3210-1NE27-5UL0 in the SINAMICS G120 family?

The closest functional alternative is the PM240 version of the same power rating, which adds integrated braking chopper and supports safety functions. The PM230 variant omits the braking chopper and safety support, so a PM240 is the direct upgrade path if those features are required.

What compliance documentation is available for this power module?

The datasheet (revision 23.06.2021) carries the Siemens declaration that changes are reserved. Standard Siemens SINAMICS G120 documentation includes CE, UL, and cUL declarations; specific certificates should be requested at quote time to match the target jurisdiction.

MPN
6SL3210-1NE27-5UL0
