Drive selection memo
The Siemens 6SL3210-5HE10-8UF0 is a SINAMICS S210 servo drive rated for 0.75 kW motor load. Input accepts 200-480 VAC three-phase at 2.8 A, 45-66 Hz; output delivers 0 V to line voltage at 2.3 A, 0-550 Hz. Frame size A measures 50 x 270 x 220 mm (WxHxD) with IP20 protection — intended for cabinet mounting, not washdown environments.
Integration notes
Mount inside an IP54-or-better enclosure given the IP20 rating. The 50 mm width fits standard DIN-rail backplanes; allow clearance above and below for airflow. Output frequency range to 550 Hz suits high-speed spindle or servo applications. Verify the DC-link braking resistor requirement for your specific load profile — the S210 family supports external braking resistors, but this variant's internal spec does not include one as standard.
