Drive selection memo
The Siemens 6SL3217-0CE32-2UA1 is a SINAMICS V10-1 AC drive rated for 22 kW output on a 3-phase 400 V supply (tolerance -15/+20%, 48-52 Hz). It delivers 150% overload for 60 seconds and 100% for 240 seconds on a 300-second cycle, which means it handles short-duration peak loads like a crusher start or a conveyor breakaway without tripping — sized for a 22 kW 4-pole induction motor on a constant-torque application. The FSD frame size (401 x 260 x 223 mm, H x W x D) and IP21 protection suit it for clean, indoor panel mounting — not washdown or outdoor duty. The BOP (Basic Operator Panel) is included for local parameter access and commissioning. Ambient rating is 0 to +50 °C; no derating curve is listed here, but standard SINAMICS practice is to derate output current above 40 °C. Plan for adequate ventilation in the enclosure if the drive runs near its full rating in a warm cabinet.
Integration checklist
No built-in EMC filter on this variant — the description explicitly says 'without filter'. If the installation must meet EN 61800-3 Category C2 or C3 conducted emission limits, an external line filter is required. Mount it close to the drive input to keep the unfiltered cable run short. The FSD frame has a standard gland-plate footprint. Cable entry from below is typical; leave at least 100 mm clearance above and below for airflow and cable bending radius. The IP21 rating means no gasketed seal — keep the enclosure clean and dry.
