Power module for 500-690 V lines with energy recovery
The Siemens 6SL3225-0BH32-2AA1 is a SINAMICS G120 PM260 Power Module built for 500-690 V 3 AC supplies, with an integrated class A filter and regenerative capability that recovers braking energy back to the line. It is listed as a spare part, lifecycle stage mature. Rated for high overload duty: 22 kW at 200% for 3 seconds, 150% for 57 seconds, 100% continuous over 240 seconds, with ambient up to +50 °C. For low overload applications it delivers 30 kW at 140% for 3 seconds, 110% for 57 seconds, 100% continuous, ambient to +40 °C.
The module measures 634 x 350 x 316 mm (HxWxD), FSF frame size, IP20 protection. It mounts in a standard enclosure backplate; no Control Unit or BOP is included — those are ordered separately and plug onto the front interface.
