The Siemens 6SL3320-1TH32-2AA0 is a SINAMICS Single Motor Module marked as a spare part, rated for a 1035 V DC input and a 690 V three-phase AC output at 215 A, with internal air cooling and a DRIVE-CLiQ cable included. The 215 A continuous output at 690 V AC means this module drives a motor load of roughly 250 kW on a 690 V line — sized for a large conveyor, pump, or compressor in a medium-voltage drive cabinet.
Lifecycle and Sourcing Reality
For a BOM line that needs this exact module, the mature status means supply is stable through independent distribution channels; we source and quote it to order against an RFQ, with availability and current pricing confirmed at quote time.
What the Ratings Mean for Fit
The 1035 V DC input is the DC-link voltage from a SINAMICS line-side converter or common DC bus — this module is not a standalone drive; it requires a DC supply from a matched rectifier or regenerative unit. The 690 V AC output and 215 A rating define the motor-side capability: it delivers 215 A per phase at 690 V, which corresponds to about 250 kW for a standard induction motor. Internal air cooling means it rejects heat into the cabinet; verify cabinet airflow and ambient temperature derating if the enclosure is sealed. The included DRIVE-CLiQ cable connects the module to a SINAMICS control unit (CU) for communication and parameter download — no separate cable procurement needed for the initial install.
