The 1SAP122600R0172: Processor module PM5012-T-ETH. 1008 kB user data memory (RAM). 6 digital inputs, 24 VDC. 4 transistor outputs, 24 VDC. Ethernet interface plus one option slot for expansion. Supply voltage range 20.4-28.8 VDC — keep it on a regulated 24 V bus. Instruction processing time 0.0002 ms, fast enough for discrete logic but not motion control.
1SAP122600R0172 Processor Module, 6 DI 4 DO, Ethernet
MPN1SAP122600R0172
Active
ABB PM5012-T-ETH Processor module 1SAP122600R0172, 1008 kB memory, 6 DI 24 VDC, 4 DO-Transistor 24 VDC, Ethernet interface, 1 option slot.
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Input voltage type | DC |
| Memory type user data | RAM |
| Additional information (Product main type) | PM5012 |
| Supply voltage | 20.4 ... 28.8 V DC |
| Voltage | 24 V DC |
| Certificates and declarations (REACH date) | 20241206 |
| Certificates and declarations (REACH information) | True - contains substances > 0.1 mass percentage |
| CN8 | 85371091 |
| Function | Memory 1MB. 6 DI 24 VDC. 4 DO-Transistor 24 VDC. Ethernet interface. 1 option slot |
| Memory size | 1008 kB |
| Number of digital inputs | 6 |
| Number of digital outputs | 4 |
| Controller processing time | 0.0002 ms |
| Certificates and declarations (SCIP) | fb22534c-9b53-478e-b4ea-b8515930ed0a Germany |
| Number of digital configurable i (Os) | 0 |
Product details
Frequently asked questions
What is the function of this module?
It is a processor module with 1008 kB memory, 6 digital inputs 24 VDC, 4 transistor outputs 24 VDC, an Ethernet interface, and one option slot for expansion (PM5012-T-ETH).
What compliance documentation is available?
RoHS compliance (EU Directive 2011/65/EU) and REACH declaration (substances above 0.1% mass) are on file. The CN8 code for customs is 85371091.
What is the supply voltage requirement?
Rated 24 VDC, operating range 20.4-28.8 VDC. Use a regulated 24 V supply for reliable operation.
