The 1SAP240600R0001: CN8 customs code is 85389091 — carry that on the shipping documentation. The module draws 5 mA per input channel. Supply voltage range 20.4 … 28.8 V DC; delay configurable 0.1 … 32 ms. No analog channels — all 16 are digital configurable. The 8 auxiliary 0 V terminals and 8 auxiliary 24 VDC terminals simplify field wiring distribution.
ABB 1SAP240600R0001 DC522 Digital I/O Module, 16 DI/DO 24VDC
MPN1SAP240600R0001
Active
ABB DC522, 1SAP240600R0001, distributed digital I/O module, 16 configurable DI/DO, 24 VDC 0.5 A transistor output, IP20.
$652.78Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Input voltage type | DC |
| Output voltage type | DC |
| Additional information (Product main type) | DC522 |
| Supply voltage | 20.4 ... 28.8 V DC |
| Maximum input voltage | 0 ... 30 V |
| Output voltage | 24 V DC |
| Output voltage maximum | 20.4 ... 28.8 V |
| Input current | 5 mA |
| Output current | 0.5 A |
| IP rating | IP20 |
| Certificates and declarations (REACH date) | 20241206 |
| Certificates and declarations (REACH information) | True - contains substances > 0.1 mass percentage |
All specifications
| Parameter | Value |
|---|---|
| CN8 | 85389091 |
| Output | Transistor |
| Function | 16 configurable DI/DO: 24VDC 0.5A. 8 aux. terminals 0 V. 8 aux. terminals 24VDC |
| Delay time (τ) | 0.1 ... 32 ms |
| Ambient air temperature | Operation 0 ... +60 °C |
| Certificates and declarations (SCIP) | 3057eee4-0247-4304-9e95-58b4d0688cb8 Germany |
| Number of analog configurable i (Os) | 0 |
| Number of digital configurable i (Os) | 16 |
Product details
Frequently asked questions
What is 1SAP240600R0001's listed CN8 code?
The CN8 customs code is 85389091.
What is the formal product title for 1SAP240600R0001?
The product is titled 'Digital input/output module. 16 configurable DI/DO: 24VDC 0.5A. 8 aux. terminals 0 V. 8 aux. terminals 24VDC (DC522)'.
MPN
1SAP240600R0001
