ABB 1SDA068100R1 XT4N 160 TMA 80A 4-Pole

MPN1SDA068100R1

ABB XT4N Series, XT4N 160 TMA 80-800 4p F F Distribution Circuit Breaker, 80 A rated, 160 A frame, 4-pole, 690 V.

$525.00Ref. price · indicative, final on quote
ABB 1SDA068100R1 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1SDA068100R1 — Electrical
ParameterValue
Rated current (In)80 A
Number of poles4 poles
Rated voltage (Ur)690 V
Rated uninterrupted current (Iu)160
Rated frequency50 / 60 Hz
1SDA068100R1 — Protection
ParameterValue
Trip unitTMA
1SDA068100R1 — Mechanical
ParameterValue
Dimensions (L x W x H)8.25cm x 14cm x 16cm
Weight3.1 Kg
1SDA068100R1 — Identification
ParameterValue
Type designationXT4N 160 TMA 80-800 4p F F
Product type designationXT4N 160 TMA 80-800 4p F F Distribution Circuit Breakers
SizeXT4
1SDA068100R1 — Other specifications
ParameterValue
In80

Product details

Breaker identity and key ratings

The ABB 1SDA068100R1 is an XT4N 160 molded case circuit breaker rated for 80 A continuous (In) on a 160 A frame (Iu), with a TMA thermal-magnetic trip unit and four poles. The rated voltage is 690 V at 50/60 Hz.

Mounting follows the standard XT4 pattern; verify that the panel cutout and busbar spacing accommodate the 4-pole width before committing the BOM line.

No pin-compatible drop-in alternative exists that matches both the 80 A In and 160 A Iu in a 4-pole fixed version.

Frequently asked questions

What are the continuous current ratings?

The breaker has a rated current (In) of 80 A and a frame rating (Iu) of 160 A. The TMA trip unit can be adjusted within the 80–800 A range.

How many poles does it have?

Four poles, for three-phase plus neutral distribution.
