ABB XT4N 160 distribution circuit breaker, 40 A, 3-pole, Ekip LS/I trip unit, 690 V.
| Parameter | Value |
|---|---|
| Number of poles | 3 poles |
| Parameter | Value |
|---|---|
| In | 40 |
| Iu | 160 |
| Dimensions | XT4 |
| Type | XT4N 160 Ekip LS/I In=40A 3p F F |
| Weight | 2.1 Kg |
| Trip units | Ekip LS/I |
| Product type | Distribution Circuit Breakers |
| Dimensions (LxWxH) | 8.25cm x 10.5cm x 16cm |
| Current | 40 A |
| Voltage | 690 V |
| Rated frequency | 50 / 60 Hz |
The ABB 1SDA068122R1 is a 3-pole distribution circuit breaker in the XT4 frame, rated 40 A continuous (In) with a frame rating of 160 A (Iu). It carries the Ekip LS/I trip unit for long-time and short-time protection — so it's a fit for feeder or branch circuits in a panel, not motor duty where you'd need a thermal-magnetic or motor-specific curve.
The 40 A rated current (In) sets the continuous load. Rated voltage is 690 V AC, frequency 50/60 Hz.
Rated current In = 40 A, frame rating Iu = 160 A, 3-pole, rated voltage 690 V, rated frequency 50/60 Hz, trip unit Ekip LS/I.
Submit an RFQ for pricing and availability. The estimated lead time is 2–4 weeks.
