ABB 1SDA068164R1 — Molded Case Circuit Breakers (MCCB)

ABB 1SDA068164R1 XT2S 160 Breaking Part, 3p F F, Iu 160 A

MPN1SDA068164R1

ABB XT2S 160 breaking part, 3-pole F F, order code 1SDA068164R1, Iu 160 A, Icu 50 kA at 415 V, 690 V rated.

$143.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1SDA068164R1 — Ratings
ParameterValue
Number of poles3 poles
1SDA068164R1 — Other specifications
ParameterValue
Iu160
DimensionsXT2
TypeXT2S 160 BREAKING PART 3p F F
Weight1 Kg
Icu (415 v)50
Product typeBreaking Part
Dimensions (LxWxH)8.25cm x 9cm x 13cm
Voltage690 V
Rated frequency50 / 60 Hz

Product details

The ABB 1SDA068164R1 is a 3-pole breaking part in the XT2S 160 frame, rated Iu 160 A continuous current. This is the interrupting section of the molded-case breaker — the part that opens the circuit under fault — not the complete breaker assembly.

The Iu 160 A rating sets the continuous current the breaker's thermal-magnetic trip unit will carry without tripping. For selective coordination studies, you'll want the Ics (service breaking capacity) from the full breaker datasheet; this breaking part alone doesn't carry that number.

Frequently asked questions

What is the Iu rating of 1SDA068164R1?

The rated uninterrupted current Iu is 160 A. That's the continuous current the breaker's trip unit is sized for.

What frame size is this breaking part?

It's the XT2 frame, the smallest in the ABB XT series. The breaking part is specific to that frame and won't fit larger XT4 or XT5 bases.
