ABB 1SDA068169R1 — Molded Case Circuit Breakers (MCCB)

ABB 1SDA068169R1 XT2S 160 Breaking Part, 4P, Iu 160 A

MPN1SDA068169R1

ABB XT2S 160 breaking part, 4-pole, Iu 160 A, Icu 50 kA at 415 V AC, 690 V rated, 50/60 Hz, DIN-rail mount.

$179.00Ref. price · indicative, final on quote
ABB 1SDA068169R1 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1SDA068169R1 — Ratings
ParameterValue
Number of poles4 poles
1SDA068169R1 — Other specifications
ParameterValue
Iu160
DimensionsXT2
TypeXT2S 160 BREAKING PART 4p F F
Weight1.2 Kg
Icu (415 v)50
Product typeBreaking Part
Dimensions (LxWxH)8.25cm x 12cm x 13cm
Voltage690 V
Rated frequency50 / 60 Hz

Product details

The ABB 1SDA068169R1 is an XT2S 160 breaking part, 4-pole, rated Iu 160 A continuous. It is not a complete MCCB — it is the interrupter mechanism without a trip unit, functioning as a switch-disconnector or as the base for a field-installed trip block.

Rated voltage and frequency — what the 690 V and 50/60 Hz mean on the line

Rated voltage Ur 690 V AC covers standard 400/480 V systems with 50% headroom, and also suits 690 V mining, marine, or industrial installations where the line-to-line voltage is higher.

Frequently asked questions

What is the Iu rating of 1SDA068169R1?

The Iu (continuous rated current) is 160 A. This is the current the breaking part is designed to carry continuously without exceeding temperature rise limits, and is the value the thermal-magnetic trip unit would be sized to if one were installed.

What compliance documentation does ABB provide for 1SDA068169R1?

ABB provides standard compliance documentation including RoHS and REACH declarations, and the part carries IEC and UL certifications as standard for the XT2 series. Specific certificates are available on request with the RFQ.
