ABB 1SDA068181R1

ABB 1SDA068181R1 XT4L 250 Breaking Part, 250 A

MPN 1SDA068181R1

ABB XT4L 250 Breaking Part 4p F F, 1SDA068181R1, Iu 250 A, Icu 120 kA @ 415 V, Size XT4.

$738.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

1SDA068181R1 specifications
ParameterValue
Product typeXT4L 250 BREAKING PART 4p F F
Voltage690 V
Frequency50/60 Hz
Poles4 poles
Weight2.7 Kg
DimensionsXT4

Product details

The ABB 1SDA068181R1 is a breaking part — the main circuit breaker unit — in the XT4L 250 series, rated for continuous current Iu 250 A and 4-pole configuration (F F terminals). It's the core component for a molded case circuit breaker designed for distribution and motor protection in industrial panels.

Size XT4 defines the physical frame: busbar centers, mounting hole pattern, and accessory footprint (e.g., shunt trips, auxiliary contacts) are all XT4-family specific. If you're replacing an existing unit, verify the panel cutout matches XT4 dimensions.

Integration note

Four-pole breakers require a 4-pole busbar or separate phase-neutral jumpers.
