ABB 1SVR011715R1200

ABB 1SVR011715R1200 CC-E I/I Signal Converter, 0-20 mA Input

MPN 1SVR011715R1200

ABB CC-E I/I Signal Converter, singlef., 1SVR011715R1200, 0...20 mA input, 4...20 mA output, ± 0.5 % accuracy, 200 µs response time, 24 V DC, IP20.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

1SVR011715R1200 specifications
ParameterValue
Product typeCC-E I/I Signal converter, singlef.
Supply voltage24 V DC
IP ratingIP20
Output signal4 / 20 mA
Response time200 μs
Temp operating max80 °C
Temp operating min-20 °C
Weight0.084 Kg
Accuracy±0.5% of Full Scale

Product details

The ABB 1SVR011715R1200 is a CC-E I/I signal converter that takes a 0...20 mA input and outputs a 4...20 mA signal. This single-function device is what you reach for when a PLC analog input expects a live-zero 4-20 mA loop but your transmitter puts out a 0-20 mA signal — or when you need galvanic isolation between field wiring and the control card. The ±0.5 % of full-scale accuracy means the output tracks the input within 0.1 mA at 20 mA span, tight enough for most process monitoring and control loops without a separate calibration trimmer in the signal path.

Response time and loop dynamics

With a 200 µs response time, this converter keeps up with fast-changing signals — pressure spikes on a hydraulic press, flow surges in a filling line, or a valve positioner that needs to see the setpoint update within a millisecond. That speed also means it won't add a noticeable lag in a cascade loop. The 24 V DC supply powers the internal electronics and the output loop; watch the total loop resistance if you're driving a long cable run or multiple receivers. The IP20 housing means this goes inside an enclosure — not on the machine frame exposed to washdown or dust.
