ABB 1SVR360563R1001
MPN1SVR360563R1001
Power Supply, (UPS), 240W, 90-300VDC, 85-264VAC|5 Amp, Power Supply, DIN Mount, Input Voltage: 85-264VAC 90-300VDC, IP20 Housing and Terminals, Hardwired 20-10 AWG, 240W Power Output
$137.16 – $341.88Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Depth | 136 mm |
| Width | 40 mm |
| Height | 129.4 mm |
| Series | CP |
| Outputs | 1 |
| Output signal | Adjustable |
| Rated power | 120 W |
| Output current 1 | 7.5 A |
| Output voltage 1 | 24 V |
| Termination type | Screw Terminal |
| IP rating | IP20 |
| Input voltage max. | 264 V |
| Input voltage min. | 85 V |
| Insulation voltage | 300 V |
| Input voltage nominal | 100 ... 240 VAC;110 ... 300 VDC |
| Output voltage nominal 1 | 24 V |
| Operating temperature max. | 70 °C |
| Operating temperature min. | -25 °C |
MPN
1SVR360563R1001
