IP67 sealed relay for wet-area control
The ABB 1SVR405601R3000 (CR-P230AC2) is a pluggable interface relay with an IP67-rated enclosure, meaning the relay body and socket interface are sealed against water ingress — suitable for washdown zones in food processing, car washes, or outdoor cabinets where standard open-frame relays fail from moisture tracking across the coil-to-contact gap. Contact configuration is 2 CO (SPDT) rated 8 A at 250 V, giving you two independent changeover circuits per relay — enough to switch a pilot light and a solenoid valve from one coil signal without an extra relay.
Coil drive and cycle life
Mechanical life exceeds 30 million cycles, and electrical life is greater than 100,000 cycles at rated load — the mechanical figure matters for high-speed sorting lines where the relay cycles faster than once per second; the electrical figure governs at full 8 A switching.
Panel fit and socket mounting
Mounting is on a separate socket (not included), so the relay unplugs for replacement without disturbing wiring — a standard MRO practice: swap the relay in seconds, leave the socket and field wiring in place.
