ABB 1SVR405618R2100

ABB 1SVR405618R2100 CR-M Relay, 4PDT, 6A, 120VAC Coil

MPN 1SVR405618R2100

ABB CR-M series interface relay, 1SVR405618R2100, 4PDT, 6 A at 250 VAC, 120 VAC coil, 14-blade base, socket mount, LED indication, gold-plated contacts.

$12.19 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

1SVR405618R2100 specifications
ParameterValue
Product typeRelay
Current6 A
Poles4
MountingSocket

Product details

CR-M interface relay with gold contacts

The ABB 1SVR405618R2100 is a CR-M series interface relay — a 4PDT (four-pole double-throw) form with a 120 VAC coil and a 6 A switching rating at 250 VAC. The gold-plated contacts handle low-level signal switching without the oxidation issues that plague tin-plated contacts in dry-circuit applications.

Socket-mount form factor and 14-blade base

Mounts into a standard 14-blade socket — the relay body snaps in and the blade pattern matches the CR-M series socket footprint. The LED indication across the coil terminals gives a quick visual on coil power without a meter.

Switching capacity and coil draw

Rated 6 A at 250 VAC per pole — this covers most general-purpose pilot duty, solenoid valve, and small motor contactor coil loads inside a panel. The 120 VAC coil draws roughly 1.5 VA typical, well within a standard 120 V control transformer's capacity.

MPN
1SVR405618R2100
