The ABB 2TLA050056R5100 is a Sense7 5M safety sensor, built for washdown environments. The IP69K protection class means the housing and optics survive high-pressure, high-temperature spray cleaning — standard for food, beverage, and pharmaceutical lines where sanitation cycles are aggressive. It ships with a PVC 8-core cable, 6 mm outer diameter, terminated and ready for the control cabinet. The cable is the fixed connection — no quick-disconnect; plan your gland entry and cable length before mounting. The dielectric withstand rating is 250 VAC, and the minimum switched current is 10 VDC at 1 mA — this means the sensor contacts can reliably switch low-level signals common to safety PLC inputs without needing a wetting current booster.
ABB 2TLA050056R5100 Sense7 5M Sensor, IP69K, PVC Cable
MPN2TLA050056R5100
ABB Sense7 5M Sensor, 2TLA050056R5100, IP69K, PVC 8-core 6mm cable, 0.3 kg.
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Weight | 0.3 Kg |
| Parameter | Value |
|---|---|
| Color | Red or stainless steel |
| Material | UL approved polyester |
| Cable type | PVC 8 core 6 mm O.D |
| Product type | Sense7 5M Sensor |
| Mounting bolts | 2 x M4 Tightening torque 1.0 Nm |
| IP rating | IP69K |
| Dimensions (LxWxH) | 1.3cm x 5cm x 8.8cm |
| Dielectric withstand | 250 VAC |
| Minimum switched current | 10VDC 1mA |
Product details
Frequently asked questions
What is the IP rating of this sensor?
IP69K — the housing and optics withstand high-pressure, high-temperature washdown cycles typical in food and beverage lines.
What cable does the 2TLA050056R5100 use?
A fixed PVC 8-core cable, 6 mm outer diameter. No quick-disconnect; plan the gland entry accordingly.
Where can I buy 2TLA050056R5100?
Sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time.
