The ABB 3AXD50000268436 is an ACQ580-01-10A6-2+P918 LV AC wall-mounted drive, built for water and wastewater applications. It runs on 208-240 V three-phase input, 50/60 Hz, and is rated for 4.2 kVA apparent power output.
Sizing and mounting
Wall-mounting with NEMA Type 1 enclosure and IP21 protection — suitable for indoor, non-hazardous locations where drips and falling dirt are the concern. Maximum ambient temperature 40 °C, so keep ventilation clear and avoid stacking heat sources above the drive.
Rated IE2 efficiency class — meets the minimum for most industrial installations in regions where IE2 is still accepted for variable-torque loads. WEEE Category 5 (small equipment under 50 cm) applies for end-of-life take-back obligations.
