3AXD50000296729 - ABB
MPN3AXD50000296729
Active
LV AC wall-mounted drive for HVAC, 6.6 A, 208... 240 V (ACH580-01-06A6-2+B056)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Output current, normal duty (In) | 6.6 A |
| Output power, light-overload duty (PlD) | 1.5 Hp |
| Apparent power output | 2.6 kV·A |
| Efficiency class (IE) | IE2 |
| Standby loss | 13 W |
| Parameter | Value |
|---|---|
| Input voltage range | 208 ... 240 V |
| Number of phases | 3-phase |
| Frequency | 50/60 Hz |
| Parameter | Value |
|---|---|
| Temperature rating, max. | Maximum 40 °C |
| Parameter | Value |
|---|---|
| Degree of protection (IP) | IP55 |
| Enclosure type (NEMA) | Type12 |
| Frame size | R1 |
| Mounting type | Wall-mounting |
MPN
3AXD50000296729
