The A16-80L-00-84 is an 8-pole, 30 A lighting contactor from the GE A-Line series, with a 120 V AC control coil and 600 V rated contacts. It's electrically held — no latching mechanism — so the coil must stay energized to keep the load connected. The contactor ships mounted on a 6-inch length of DIN rail, saving panel-builder layout time.
What the Ratings Mean for Fit
30 A per pole at 600 V is the contact rating — sized for lighting banks, resistive heater loads, or small motor groups where the inrush stays under the contactor's make/break capability. Eight poles give you four independent contact sets (or parallel them for higher current on a single phase). The 120 V AC coil is standard for North American control circuits; verify your control transformer matches before wiring.
Deployment Context
Open-type construction means it's intended for enclosure mounting — the DIN rail it ships on snaps into a standard 35 mm rail inside a panel. Use it in lighting contactor panels, HVAC control cabinets, or industrial machine centers where a multi-pole contactor with a common coil is needed. The electrically held design draws continuous coil current, so factor that into your control transformer sizing.
