ABB A16N0-30-10-84 — Contactors

A16N0-30-10-84 NEMA Size 0 Contactor, 18A, 3P, 120VAC Coil

MPNA16N0-30-10-84
End of Life

Furnas A-Line NEMA Size 0 contactor, 18A, 3-pole, 120VAC coil, 1 N.O. auxiliary contact block, non-reversing, 600V rated.

$289.27Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

A16N0-30-10-84 — Specifications
ParameterValue
Amps18
TypeNEMA
Poles3
Volts AC control120

Product details

What you're looking at

This is a Furnas A-Line NEMA Size 0 contactor, order code A16N0-30-10-84. It's a 3-pole, non-reversing magnetic contactor rated 18 A, with a 120 VAC coil and a single normally-open auxiliary contact block built in. The 600 V rating covers motor and general-load switching in a NEMA-style panel.

The 18 A rating and NEMA Size 0 — what that means on the line

NEMA Size 0 is a standard frame size for contactors up to about 18 A full-load current for three-phase motors. For a typical 460 V motor, that's roughly a 7.5 HP motor load. The 120 VAC coil means it needs a control transformer or separate 120 V control circuit to pull in — common in legacy panel builds where the control voltage is separate from the motor power.

What you get in the box

The A16N0-30-10-84 includes one normally-open auxiliary contact block. That's a spare set of contacts for status feedback or interlocking. The contactor is 3-pole, non-reversing — meaning it switches all three phases together and only one direction. If you need reversing, you'd pair two of these with a mechanical interlock.

Frequently asked questions

Where can I buy A16N0-30-10-84?

This part is sourced to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time.

What is the closest alternative to A16N0-30-10-84?

No official successor is listed in the record. For a functional equivalent, you'd need to compare NEMA Size 0 contactors from other manufacturers or the same A-Line family with a different coil voltage, but that's not a pin-compatible drop-in without verifying the coil and mounting.
