Rated 302 A motor current (AC-3 duty) and 400 A general-purpose (AC-1) at 600 V. The 400 A resistive rating covers heater banks or lighting where the inrush is minimal. The 1 N.O. + 1 N.C. auxiliary contact block is built in, saving a separate add-on for status feedback or interlocking. Three-pole IEC contactor in the A300 frame size. Panel integration is standard DIN-rail or through-panel mount; the frame determines the terminal spacing and busbar pitch for the line and load connections.
Eaton A300-30-11-84 Contactor, 302A, 120V Coil, EOL
MPNA300-30-11-84
End of Life
Eaton A-Line Series, A300 frame, 3-pole IEC contactor, 302 A motor current, 400 A general purpose, 600 V rated, 120 V AC coil, 1 N.O. + 1 N.C. auxiliary contact block.
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Amps | 302 |
| Type | Contactor |
| Poles | 3 |
| Volts AC control | 120 |
Product details
Frequently asked questions
Where can I buy A300-30-11-84 and how do I get a price?
This part is sourced to order against an RFQ through independent distribution channels. Availability and current pricing are confirmed at quote time.
What is A300-30-11-84's listed amps (302) on this component line?
The 302 A rating is the motor current (AC-3 duty) for switching three-phase induction motor loads. The general-purpose resistive rating is 400 A (AC-1).
What is A300-30-11-84's listed type on this component line?
It is a 3-pole IEC contactor from the Eaton A-Line Series, A300 frame, with a 120 V AC coil and a built-in 1 N.O. + 1 N.C. auxiliary contact block.
MPN
A300-30-11-84
