125 A Contactor — Non-Reversing, 230-240VAC Coil
The Eaton A75-30-11-80 is a 3-pole non-reversing contactor rated at 125 A, with a 230-240VAC coil and screw terminals. It includes one normally open and one normally closed auxiliary contact (1 NO + 1 NC). The 125 A rating means it handles motor loads up to that current in AC-3 duty — sized for a 55–60 kW induction motor on a 400 V line, typical for conveyor drives, pumps, or compressors in a control panel.
Panel Integration & Wiring
Screw terminals accept standard power and control wiring — strip length and torque per the manufacturer's terminal marking on the contactor body. The 1 NO + 1 NC auxiliary block is built in, so no separate add-on is needed for basic feedback or interlocking.
