105 A / 80 A Motor — What the Ratings Mean
The A75-30-11-84 is an IEC contactor rated 105 A general purpose and 80 A motor full-load current at 600 VAC, 3-pole, with a 120 VAC coil. The 80 A motor rating is the one that governs for pump, fan, or compressor starts — the 105 A figure applies to resistive loads where inrush is minimal. The built-in 1 N.O. + 1 N.C. auxiliary contact block saves a separate add-on for basic feedback or interlock wiring. Three poles handle three-phase motor circuits; the 120 VAC coil matches standard North American control voltages.
End-of-Life — Sourcing Reality for the A75-30-11-84
For a BOM freeze or a line-down replacement, the A75-30-11-84 is sourced to order against the RFQ. Current pricing and stock position are confirmed at quote time — no stock-holding claim is made here.
A75 Frame — Panel Fit and Mounting
The A75 frame contactor snaps onto standard DIN rail — no screws needed for the mount. The 3-pole block occupies a single module width; the auxiliary block adds one side module. Coil terminals are clearly marked A1/A2; power poles are line/load on opposite faces.
