ABB ACS5500106A94 — AC Drives (VFD)

ABB ACS5500106A94 Frequency Inverter, 3/2.2 kW, IP21

MPNACS5500106A94
End of Life

ABB ACS550-01-06A9-4 frequency inverter, 3-phase 380–480 V AC input, 0–500 Hz output, 3/2.2 kW motor power, IP21, R1 frame, listed as used.

$1,272.54Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

ACS5500106A94 — Mechanical
ParameterValue
Frame sizeR1
Weight6,16 kg
ACS5500106A94 — Other specifications
ParameterValue
TypeFrequency Inverter
ModelACS550-01-06A9-4
Voltage3 phase/380 … 480 V AC
ConditionUsed
Frequency0 … 500 Hz
Shelf no.240620
Dimensions212 x 125 x 369 mm
ManufactureAbb
Motor power3/2.2 Kw
Current6.9 / 5.4 A
Dimensions [mm]212 x 125 x 369
Output: voltage3 phase/0 … 380 … 480 V AC
Type of productFrequency Inverter
IP ratingIP21

Product details

What you're actually getting

The ABB ACS5500106A94 is the same drive as the canonical ACS550-01-06A9-4 — the order code on the listing is a reformat of the standard catalog number rather than a different variant, so it drops into a panel cut for the ACS550-01 frame without remapping I/O or changing the parameter file structure. It is a 3-phase 380 … 480 V AC input frequency inverter, frame size R1, IP21 enclosure, with a 3-phase 0 … 380 … 480 V AC output spanning 0 … 500 Hz — sized for a 3/2.2 kW motor at 6.9/5.4 A rated current.

Reading the two current numbers

The 6.9/5.4 A pair is the load-bearing figure for motor sizing: 6.9 A is the heavy-duty (constant-torque) rating and 5.4 A is the light-duty / variable-torque rating, which mirrors the 3/2.2 kW dual rating. The drive will deliver full torque at the higher current only if the motor nameplate falls inside that envelope — overspec the motor and the inverter clips current rather than voltage.

Sourcing posture

For a panel already specified around the ACS550-01-06A9-4, the ACS5500106A94 string is mechanically and electrically the same drive, so the BOM line holds without rewiring; ratings, footprint, and parameter set carry over.

Frequently asked questions

What type of drive is the ACS5500106A94?

It is listed as a Frequency Inverter — the ACS550-01-06A9-4 model in ABB's ACS550 series, 3-phase 380 … 480 V AC, IP21, R1 frame.

Will the ACS5500106A94 drop into a panel built around the ACS550-01-06A9-4 without rewiring?

Yes — it is the same drive, same R1 frame, same 3-phase 380 … 480 V AC input, same 3/2.2 kW / 6.9/5.4 A rating class, so the existing panel cut and wiring land on the same terminals and parameter set.

What is the motor sizing for this drive?

3/2.2 kW with 6.9/5.4 A rated current (heavy-duty / light-duty), output 0 … 500 Hz at 3-phase 0 … 380 … 480 V AC.

How is the ACS5500106A94 supplied?

The listing is marked as used with shelf-tag 240620, indicating the surplus/secondary channel; supply is quoted to order against an RFQ rather than off a current production line.

MPN
ACS5500106A94
