130 A three-pole contactor with wide-range coil
The ABB AF146-30-11-13 is a 3-pole contactor rated 130 A continuous, with a maximum insulation voltage of 600 V AC. The wide control voltage range of 100-250 V AC/DC means one coil covers both 110 V and 220 V control circuits — no coil swap when the panel line voltage changes between sites. Rated for motor starting, isolation, bypass, and distribution switching up to 1000 V, this contactor fits into a standard 3-phase load circuit on a DIN-rail panel. The 130 A frame handles a 50-75 hp motor at 480 V depending on the duty cycle and ambient derating.
Control voltage flexibility and coil draw
The 100-250 V AC/DC control range covers 110 V, 120 V, 208 V, 220 V, and 240 V control transformers without changing the coil. The electronic coil interface draws a low holding power — typically under 10 VA — so the PLC output or control relay driving it sees a light load. Because the coil accepts DC as well as AC, the contactor can be driven directly from a 24 V DC control bus if a DC-rated coil variant is selected; the AC/DC designation on this unit means it handles both waveforms across the stated range.
Lifecycle and sourcing for the BOM line
The ABB AF146 series shares the same mounting footprint and terminal layout across the current range, so a panel layout designed for a 130 A frame accepts the 150 A or 185 A frame without re-drilling the DIN rail.
