ABB AF26-22-00-13

AF26-22-00-13 ABB Contactor, 45A, 4-Pole, 100-250V Coil

MPN AF26-22-00-13

ABB, AF-Line Series, IEC Contactor, AF26-22-00-13, 45 Amp, 4-Pole, 100-250 VAC/VDC Coil, 600V Rated.

$39.37 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

AF26-22-00-13 specifications
ParameterValue
Product typeContactor
Current45 A
Poles4

Product details

What the 45 A rating means for fit

The 100-250 VAC/VDC coil gives you flexibility across control voltages — same part works for a 120 V or 240 V control circuit, AC or DC. The 4-pole configuration (2 N.O. + 2 N.C. main contacts) suits applications needing both make and break on the same device, like reversing or two-speed motor starters where you need to disconnect one winding before engaging another.

This AF26 frame contactor snaps onto a DIN rail — standard 35 mm. The 100-250 V coil range means you don't need a separate control transformer if your panel runs at 240 VAC. Note the description states this unit does not include standard auxiliary contacts, so if you need feedback to a PLC or status indication, order the aux contact block separately. The 600 V rated insulation gives headroom for 480 V systems without derating.

MPN
AF26-22-00-13
