ABB AF52-30-00-11

AF52-30-00-11 ABB Contactor, 54A, 24-60V AC/DC Coil

MPN AF52-30-00-11

ABB AF52-30-00-11, 3-pole contactor, 54A, 100A across-the-line rating, 24-60V AC/DC coil.

$237.59 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

AF52-30-00-11 specifications
ParameterValue
Product typeContactor

Product details

The ABB AF52-30-00-11 is a three-pole contactor rated for 54 A continuous current, with a 100 A across-the-line rating and a 24-60 V AC/DC coil. The wide coil range means it can be wired into control circuits that supply 24 VDC or 48-60 VAC without needing a separate coil-voltage variant — a single part number covers multiple panel builds.

The 54 A continuous rating suits motor loads up to roughly 22 kW at 400 VAC (AC-3 duty) or resistive heating banks. The 100 A across-the-line figure is the maximum non-switching current the main poles can carry continuously — useful for infrequent isolation of a high-inrush load.

MPN
AF52-30-00-11
