ABB S201-B13NA — 1-Pole MCB (DIN Rail)

ABB S201-B13NA MCB 1P+N B 13A 480Y/277V, current lifecycle

MPNS201-B13NA

ABB S201-B13NA, 1P+N MCB, B-curve 13 A, 480Y/277 V, current lifecycle.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Product details

The ABB S201-B13NA is a 1P+N miniature circuit breaker with a B-curve trip characteristic rated at 13 A, 480Y/277 V. For motor or transformer starts that draw higher inrush, a C- or D-curve would be the better fit; this one is sized for lighting, heating, and general-purpose receptacle circuits.

For a BOM-freeze or a panel-builder stocking the S200 series, this part is still the standard catalog choice.

The 1P+N configuration switches the line conductor and provides a switched neutral — the neutral pole opens and closes with the line pole but does not have overcurrent protection. This is common for single-phase final circuits where disconnecting both poles is required by local code (e.g., for socket-outlet circuits in some jurisdictions). Rated 480Y/277 V — the Y indicates a wye system where the phase-to-neutral voltage is 277 V and the phase-to-phase voltage is 480 V. This MCB is designed for 277/480 V wye distribution, not for 240 V split-phase or 208Y/120 V without checking the voltage rating against the system.

Frequently asked questions

Where can I buy the S201-B13NA and get a price?

The S201-B13NA is sourced to order against an RFQ through independent distribution. Submit a request for quote; availability and current pricing are confirmed at quote time.

What is the S201-B13NA's description and key rating?

The ABB S201-B13NA is a 1P+N miniature circuit breaker, B-curve, 13 A, rated 480Y/277 V. It is part of the S200 series for final distribution.

MPN
S201-B13NA
