ABB S201-D6

S201-D6 Miniature Circuit Breaker, 1P, 6A, Curve D, 277V

MPN S201-D6

ABB S201-D6, 1-pole miniature circuit breaker, 6 A, Trip Curve D, 277 VAC, 6 kA interrupting rating, DIN rail mount.

$5.07 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

S201-D6 specifications
ParameterValue
Product typeTrip Curve D
Current6 A
Breaking capacity6 kA
Poles1
MountingDIN Rail

Product details

What this 6 A Curve D MCB does in the panel

The ABB S201-D6 is a 1-pole miniature circuit breaker rated 6 A with a Trip Curve D characteristic, meaning it tolerates a brief inrush up to 10–20× rated current before tripping — sized for motor and transformer starts where a standard Curve C would nuisance-trip on the magnetizing surge. Snaps onto standard DIN rail — the finger-safe terminals accept multi-function wiring, and the 1-pole format frees up adjacent slots for additional phases or auxiliary contacts in a multi-pole group.

Regulatory and compliance coverage

Listed under UL 1077 and CSA 22.2 No. 235 — accepted for supplementary protection in North American panels. The thermal-magnetic trip mechanism provides both overload and short-circuit response in a single package.

MPN
S201-D6
