ABB S201-K6NA

S201-K6NA Miniature Circuit Breaker, 6A, 1P, K Curve, 277V A

MPN S201-K6NA

ABB S200 series, miniature circuit breaker, 6 A, 1 pole, K trip curve, 277 V AC, 6 kA interrupting rating, DIN rail mount.

$8.53 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

S201-K6NA specifications
ParameterValue
Product typeTrip Curve K
Current6 A
Breaking capacity6 kA
Poles1
MountingDIN Rail

Product details

The S201-K6NA is a 1-pole miniature circuit breaker from the ABB S200 series, rated 6 A continuous at 277 V AC. The K trip curve tolerates moderate inrush for motor and transformer branch circuits. Mounts on standard DIN rail — snaps into any 35 mm rail in the enclosure. Single-pole format takes one module width (about 17.5 mm), so it fits tight panel layouts where you're stacking multiple branch circuits.

Listed as a UL 1077 supplemental protector and CSA 22.2 — that means it's recognized for branch-circuit protection in industrial control panels but is not a full UL 489 branch-circuit breaker. For a panel builder, that distinction matters: UL 1077 devices can't be used as the main service disconnect, but they're standard for protecting individual loads like contactors, relays, or small motors inside a listed panel.

MPN
S201-K6NA
