ABB S202-C16

S202-C16 ABB Miniature Circuit Breaker, 16A, 2-Pole, C-Curve

MPN S202-C16

ABB S202-C16, miniature circuit breaker, 16A, 2-pole, C-curve, 277 VAC, 6 kA interrupting rating, DIN rail mount.

$7.54 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

S202-C16 specifications
ParameterValue
Product typeTrip Curve C
Current1.6 A
Breaking capacity6 kA
Poles2
MountingDIN Rail

Product details

The ABB S202-C16 is a 2-pole miniature circuit breaker rated 16 A with a C-trip curve, designed for DIN-rail mounting in distribution panels. The 6 kA interrupting rating at 277 VAC means it can safely clear a fault up to that level without welding contacts or cascading upstream — enough for most commercial and light industrial branch circuits. The C-curve (5–10× In magnetic trip) is the standard choice for motor starters, transformers, and capacitor banks where inrush current would nuisance-trip a B-curve breaker.

Panel integration

Snaps onto standard 35 mm DIN rail. The 2-pole width occupies two modular spaces (36 mm). Spring-cage terminals accept 0.2–2.5 mm² solid or ferruled stranded — strip length 8 mm. No backplane power draw; it's a passive thermal-magnetic device.

MPN
S202-C16
