ABB S200M series, S202M-B16, 2-pole miniature circuit breaker, 16 A, Trip Curve B, 277 VAC / 125 VDC, 6 kA interrupting rating, DIN rail mount.
| Parameter | Value |
|---|---|
| Amps | 16 |
| Type | Trip Curve B |
| Poles | 2 |
| Mounting | DIN Rail |
| Volts AC | 277 |
| Volts DC | 125 |
| Breaking capacity | 6 kA |
| Interrupt rating DC | 10 kA |
At 16 A on a 277 VAC single-phase circuit, it clears a bolted fault up to 6 kA; on 125 VDC the interrupting rating climbs to 10 kA. The 2-pole construction means it switches both line and neutral (or two phases) simultaneously, which matters for 240 V split-phase panels or DC circuits where both poles break the arc.
The S202M-B16 is sourced to order through independent distribution. Submit an RFQ for current pricing and availability — quotes are confirmed at time of request with no minimum commitment.
