ABB S203-B20 — 3-Pole MCB (DIN Rail)

S203-B20 20A B-Curve 3-Pole DIN Rail Circuit Breaker, 277VAC

MPNS203-B20

ABB S200 series, S203-B20, 3-pole miniature circuit breaker, 20 A, B-curve, 277 VAC, 6 kA interrupting capacity, DIN rail mount, UL 1077 supplemental protector.

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

S203-B20 — Identification
ParameterValue
Number of poles3
S203-B20 — Electrical
ParameterValue
Voltage (AC)277
Current (A)20
S203-B20 — Protection
ParameterValue
Interrupting rating (AC)6 kA
S203-B20 — Mechanical
ParameterValue
Mounting typeDIN Rail
S203-B20 — Other specifications
ParameterValue
TypeTrip Curve B

Product details

It's a UL 1077 supplemental protector, meaning it's intended for branch-circuit protection inside listed equipment — not as a service-entrance main breaker. Rated 277 VAC line-to-neutral on a 480Y/277 V wye system, so it covers the common North American lighting and control panel voltage.

The 3-pole width (about 54 mm for three modules) fits a standard panel layout. No special busbar — the S200 series uses a common pin-and-fork bus system for feed-through or group supply. Verify the busbar pitch matches the S200 footprint before wiring.

Frequently asked questions

What is S203-B20's interrupting rating?

6 kA at 277 VAC. That's the maximum fault current it can safely interrupt under the UL 1077 supplemental protector standard.

Where can I buy S203-B20?

Sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time — no stock figures or lead-time numbers published here.
