The Eaton TF42-16 is a 3-pole thermal bimetallic overload relay rated 16 A, adjustable from 13 to 16 A, with Trip Class 10 protection. It is designed for use with AF Series contactors in the AF9 through AF38 frame sizes. The selectable manual or automatic reset gives the panel builder flexibility: auto reset for remote or unattended installations, manual reset for local fault indication on a manned line.
Eaton TF42-16 Overload Relay, 16 A, 3-Pole, Trip Class 10
MPNTF42-16
Eaton A-Line TF42-16 thermal overload relay, 16 A, 3-pole, Trip Class 10, for AF9-AF38 contactors.
$24.13Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Amps | 16 |
| Type | NEMA |
| Poles | 3 |
| Amps range | 13 - 16 |
| Family (Style) | A-Line |
Product details
Frequently asked questions
What is TF42-16's listed amps (16) on this component line?
The TF42-16 is rated 16 A with an adjustable range of 13 to 16 A.
MPN
TF42-16
