ABB XT2H 160 TMA 80-800 3p F F

ABB XT2H 160 TMA 80-800 3p F F, 80 A, 690 V, 3-pole MCCB

MPN XT2H 160 TMA 80-800 3p F F

ABB SACE Tmax XT2H moulded case circuit breaker, fixed three-pole, front terminals, TMA thermomagnetic release rated 80 A with adjustable instantaneous trip 400–800 A, 690 V AC, 160 A frame.

$482.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

XT2H 160 TMA 80-800 3p F F specifications
ParameterValue
Product typeCB
Release typeTM
Voltage690 V
Insulation voltage ui1000 V
Current80 A
Frequency50/60 Hz
Poles3
Electrical life cycles120 cycles per hour 8000 cycle
Mechanical life cyclesNr. Operations 240 cycles per hour
Opening timeCB with SOR 15 ms

Product details

The ABB XT2H 160 TMA 80-800 3p F F is a moulded case circuit breaker from the SACE Tmax XT family, built on the XT2 sub-type frame in a three-pole, fixed-front-terminal configuration for power distribution. It carries a thermal-magnetic adjustable release (TMA) set to 80 A rated current, which means the thermal element protects sustained overloads up to that figure while the magnetic element trips instantaneously somewhere in the 400–800 A window — the band the protection study has to respect when coordinating with downstream devices. The frame is rated for 160 A uninterrupted current, so the 80 A breaker is operating well under its frame ceiling; this is the part an integrator chooses when the load sits in the lower half of the XT2 size range and full XT4-class headroom is not required.

Voltage and short-circuit envelope

Rated operational voltage reaches 690 V AC at 50/60 Hz, with a 1000 V insulation rating (Ui) and an 8 kV impulse withstand (Uimp) — the numbers that govern clearance and creepage in the panel layout, not the run voltage of any single feeder. On DC strings the breaker is rated for 70 kA at 250 V DC with two poles in series, and 70 kA at 500 V DC with three poles in series, so a DC battery or PV feeder application requires the poles to be wired in series as specified — that is a wiring-diagram detail, not an option. Power loss at rated operating conditions is 5.8 W per pole; for panel thermal budgeting, multiply by the number of poles carrying full load.

Endurance and trip timing

Mechanical durability is rated for 240 cycles per hour and electrical durability for 120 cycles per hour across 8000 cycles, so the breaker is sized for normal distribution switching, not for repetitive motor-dutying where a dedicated motor-rated device would be the right pick.
