CR-range Interface Relay

434 variants · ABBAll General Purpose Relays →

About the CR-range Interface Relay

The ABB CR-range Interface Relay series groups 434 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by weight, product type and temp operating max, so you can match the exact weight your application requires using the selection guide below.

Select a variant by

Weight: 0.084 Kg · 0.085 Kg · 0.093 Kg · 0.126 Kg · 0.128 Kg · 0.132 kg · 0.269 kg
Product type: CC-E I/I Signal converter, singlef. · CC-E/RTD Temp. converter, univers. · CC-U/STD Universal signal converter · CC-U/V Universal signal converter · Monitoring relay
Temp operating max: 80 °C · 85 °C
Temp operating min: -40 °C · -20 °C
Accuracy: ±0.1 % of full-scale · ±0.5% of Full Scale
Output signal: 0 ... ± 55 mA / 0 ... .± 11 V · 0 ...5 V / 0 ... 10 V / 0 ... 20 mA / 4 ... 20 mA · 0-20 mA · 4 / 20 mA
Response time: 150 ms · 200 μs
IP rating: IP20 · IP50 / IP20

Variant comparison

Parameter	1SVR011715R1200	1SVR011718R2500	1SVR011706R2200	1SVR011714R1100	1SVR040001R0400	1SVR040008R1300
Weight	0.084 Kg	0.084 Kg	0.093 Kg	0.085 Kg	0.126 Kg	0.128 Kg
Product type	CC-E I/I Signal converter, singlef.	CC-E I/I Signal converter, singlef.	CC-E/RTD Temp. converter, univers.	CC-E I/I Signal converter, singlef.	CC-U/STD Universal signal converter	CC-U/V Universal signal converter
Temp operating max	80 °C	80 °C	80 °C	80 °C	80 °C	80 °C
Temp operating min	-20 °C	-20 °C	-20 °C	-20 °C	-40 °C	-40 °C
Accuracy	±0.5% of Full Scale	±0.5% of Full Scale	±0.5% of Full Scale	±0.5% of Full Scale	±0.1 % of full-scale	±0.5% of Full Scale
Output signal	4 / 20 mA	4 / 20 mA	0 ...5 V / 0 ... 10 V / 0 ... 20 mA / 4 ... 20 mA	0-20 mA	0 ... ± 55 mA / 0 ... .± 11 V	0 ... ± 55 mA / 0 ... .± 11 V
Response time	200 μs	200 μs	200 μs	200 μs	200 μs	150 ms
IP rating	IP20	IP20	IP20	IP20	—	—

Request a quote on any CR-range Interface Relay part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
