Drive selection memo
The Fuji FRN0115G2S-2GU is a 40 hp variable frequency drive from the FRENIC-Eco series, sized for a 114 A maximum output current at 230V AC three-phase output. It accepts 208V AC three-phase input (200-240V AC +10%/-15% range) at 50/60 Hz. The 114 A rating is the continuous output current — that's the number to match against your motor's full-load amps, not the 40 hp figure, since motor efficiency and service factor vary. Output frequency spans 0.1 to 120 Hz, covering most induction motor speed ranges for fans, pumps, and conveyors. This is a no-bypass, open-enclosure drive rated NEMA 1 (indoor use, drip-proof). It includes a built-in dynamic braking transistor — no external brake chopper needed — which matters for vertical loads or quick deceleration profiles on conveyors. The 50% starting torque at 1 Hz (variable torque application) means it handles centrifugal loads like fans and pumps cleanly without oversizing.
I/O and control summary
Control is via keypad or remote contacts. The drive accepts 7 digital and 3 analog inputs, and provides 5 digital and 2 analog outputs. The LCD/LED display shows motor speed (with percent), output frequency, output current, output voltage, alarm codes, and function codes. Start/stop is programmable; the digital readout covers the three key running parameters you'd monitor during commissioning.
Physical integration
Physical footprint: 21-3/4 inches high, 12-5/8 inches wide, 10 inches deep. Blue enclosure, open style with a heat sink. The NEMA 1 rating means it's intended for indoor panel mounting where dripping water or incidental contact is a concern, but it's not sealed against hose-down or outdoor exposure. No Ethernet port on this variant — control is via hardwired I/O or remote contacts.
