Omron CP1L-M60DT-D — PLCs (Programmable Logic Controllers)

Omron CP1L-M60DT-D PLC, 36 In 24 Out Solid State, 24VDC

MPNCP1L-M60DT-D
Active

Omron CP1L Series, Programmable Logic Controller, CP1L-M60DT-D, 24VDC, 36 Digital Inputs, 24 Solid State Outputs, 32K Words Memory.

$477.00 – $1,272.30Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

CP1L-M60DT-D — Identification
ParameterValue
SeriesCP1L
CP1L-M60DT-D — I/O
ParameterValue
Inputs (count and type)36 - Digital
Outputs (count and type)24 - Solid State
Expandable3 Modules Max
CP1L-M60DT-D — Electrical
ParameterValue
Supply voltage24VDC
CP1L-M60DT-D — Environmental
ParameterValue
Operating temperature range0°C ~ 55°C
CP1L-M60DT-D — Mechanical
ParameterValue
Mounting typeChassis Mount, DIN Rail
Weight1.8 lbs (816.5 g)
CP1L-M60DT-D — Approvals
ParameterValue
Approvals / certificationsCE, cULus, Lloyd, NK
CP1L-M60DT-D — Other specifications
ParameterValue
FeaturesBattery Backup
SoftwareCX-One
Memory size32K Words
Display typeNo Display
CommunicationsUSB, Option Cards Available

Product details

The Omron CP1L-M60DT-D is a current-production micro PLC packing 36 digital inputs and 24 solid-state outputs on a 24VDC backplane, with 32K words of program memory and room for up to three expansion modules via the side bus. It's a known runner in machine control – value's in the sort, and this one's active with no last-time-buy clock ticking yet.

Where it lands vs the relay-sibling

The CP1L-M60DR-D carries the same 36 inputs and 24 outputs but with relay contacts instead of solid-state. That means the -DT-D switches faster and has no mechanical wear, but it can't handle the same inductive surge as the -DR-D's relays. Same footprint, same supply voltage, same memory and expansion limit – the output type is the only decision break. If your panel was wired for relay outputs, the -DT-D won't drop in without swapping the output cards or re-terminating the load side.

Frequently asked questions

Will CP1L-M60DT-D drop into a panel specified around CP1L-M60DR-D without rewiring?

No, because the output type differs (solid-state vs relay). The terminal assignment and wiring for the outputs will need to be reviewed. The base unit dimensions and input wiring are identical.
