What the 36 kA rating means for your panel
Mounts on a backplate with front-connect terminals accepting compression lugs or busbars. The 12-module 9 mm pitch footprint (108 mm wide, 137 mm high, 80 mm deep) fits standard DIN-rail enclosures; the grey RAL 7016 housing matches the ComPacT family look. IP40 front face and IK07 impact resistance handle typical panel environments — not washdown, but fine for indoor switchboards.
The breaker accepts front-connect compression lugs or busbars; connection pitch is 35 mm with spreaders, 27 mm without. Neutral is on the left. The flag indicator (green) shows presence of auxiliary contacts. Electrical endurance is 20,000 cycles at 440 V at rated current, halving to 10,000 cycles at 690 V — fine for distribution duty but not for frequent switching applications. Operating altitude to 2000 m without derating; derate above that to 5000 m max.
