LC1D38N7
Schneider Electric
Resistive load Motor controlIP2070 °C
Ref. price$66.14
Lead time on requestGet quote
Schneider Electric LC1D38 Series
164 variants · Schneider Electric
About the Schneider Electric LC1D38 Series
The Schneider Electric LC1D38 Series series groups 164 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common IP rating of IP20, main product or component type of Contactor and temp operating max of 80 °C. Variants differ by application, depth and fire behavior, so you can match the exact application your application requires using the selection guide below.
Select a variant by
- Application
- Resistive load Motor control · Resistive load, Motor control
- Depth
- 3.9 in (99 mm) · 90 mm · 99 mm
- Fire behavior
- V1 conforming to UL 94 · V1 UL 94
- Height
- 3.3 in (85 mm) · 85 mm
- Permissible ambient air temperature around the device
- -76...176 °F (-60...80 °C) storage -40...140 °F (-40...60 °C) operation 140...158 °F (60...70 °C) with derating · -60...80 °C storage -40...60 °C operation 60...70 °C with derating
- Width
- 1.8 in (45 mm) · 45 mm
Shared specifications
- IP rating
- IP20
- Main product or component type
- Contactor
- Temp operating max
- 80 °C
- Temp operating min
- -60 °C
Variant comparison
| Parameter | LC1D385BD | LC1D385CD | LC1D385DD | LC1D385ED | LC1D385F7 | LC1D385FE7 |
|---|---|---|---|---|---|---|
| Application | Resistive load, Motor control | Resistive load Motor control | Resistive load Motor control | Resistive load, Motor control | Resistive load Motor control | Resistive load Motor control |
| Depth | 99 mm | 99 mm | 99 mm | 99 mm | 90 mm | 90 mm |
| Fire behavior | V1 conforming to UL 94 | V1 conforming to UL 94 | V1 conforming to UL 94 | V1 conforming to UL 94 | V1 conforming to UL 94 | V1 conforming to UL 94 |
| Height | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm |
| Permissible ambient air temperature around the device | -60...80 °C storage -40...60 °C operation 60...70 °C with derating | -60...80 °C storage -40...60 °C operation 60...70 °C with derating | -60...80 °C storage -40...60 °C operation 60...70 °C with derating | -60...80 °C storage -40...60 °C operation 60...70 °C with derating | -60...80 °C storage -40...60 °C operation 60...70 °C with derating | -60...80 °C storage -40...60 °C operation 60...70 °C with derating |
| Width | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
Request a quote on any Schneider Electric LC1D38 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
