Siemens 3RV2411-1KA15 — Motor Protection Circuit Breakers (MPCB)

Siemens 3RV2411-1KA15 SIRIUS Circuit Breaker, 100 kA at 400

MPN3RV2411-1KA15
Active

Siemens SIRIUS circuit breaker, 3RV2411-1KA15, for transformer protection, 45 mm wide, 100 kA breaking capacity at 400 V, Class 10 trip, screw and snap-on DIN rail mounting.

$48.26Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

3RV2411-1KA15 — Identification
ParameterValue
SeriesSIRIUS
Product designationCircuit breaker
Frame sizeS00
3RV2411-1KA15 — Electrical
ParameterValue
Rated operational current (Ie)12.5 A
Rated voltage20 ... 690 V
Rated voltage, AC-3 (max.)690 V
Rated frequency50 ... 60 Hz
Rated insulation voltage (Ui), pollution degree 3690 V
Rated impulse withstand voltage (Uimp)6 kV
Number of poles3
Power loss (AC, hot)9.25 W
Power loss, per pole (AC, hot)3.1 W
3RV2411-1KA15 — Protection & Tripping
ParameterValue
Overload release setting range9 ... 12.5 A
Instantaneous short-circuit trip current260 A
Trip classCLASS 10
Breaking capacity at 240 V (AC)100 kA
Breaking capacity at 400 V (AC)100 kA
Breaking capacity at 500 V (AC)42 kA
Breaking capacity at 690 V (AC)6 kA
Breaking capacity at 240 V100 kA
Breaking capacity at 690 V4 kA
Short-circuit trip typemagnetic
Overload release typethermal
Short-circuit protectionYes
Phase-failure detectionYes
Ground-fault detectionNo
Auxiliary switch extendableYes
3RV2411-1KA15 — Endurance & Switching
ParameterValue
Endurance, main contacts (typ.)100 000
Endurance, auxiliary contacts (typ.)100 000
Switching frequency, AC-3 (max.)15 1/h
Auxiliary CO (changeover) contacts0
3RV2411-1KA15 — Connections
ParameterValue
Main-circuit terminal typescrew-type terminals
Main-circuit connector arrangementTop and bottom
Conductor cross-section, solid / stranded2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Conductor cross-section, finely stranded with ferrule2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Conductor range, AWG (main contacts)2x (18 ... 14), 2x 12
3RV2411-1KA15 — Mechanical
ParameterValue
Height97 mm
Width45 mm
Depth97 mm
Mounting methodscrew and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
Mounting positionany
3RV2411-1KA15 — Environmental
ParameterValue
Operating temperature-20 ... +60 °C
Storage temperature-50 ... +80 °C
Transport temperature-50 ... +80 °C
Relative humidity (operation)10 ... 95 %
Max. installation altitude2 000 m
3RV2411-1KA15 — Specifications
ParameterValue
Design Of The ProductFor transformer protection

Product details

It's a current-production part, so it's still rolling off the line — no hunting through surplus bins yet.

Breaking capacity varies by voltage: 100 kA at 240 V and 400 V, 42 kA at 500 V, and 4 kA at 690 V. At 690 V, the 4 kA figure is the limit — if your fault current exceeds that upstream, you'll need a current-limiting upstream device. The fuse back-up ratings (gL/gG 63 A at 400 V, 50 A at 500 V, 40 A at 690 V) tell you the maximum fuse size that preserves coordination; oversize the fuse and the breaker takes more fault energy than it's rated for.

The M3 main contact terminals accept 2× (0.5 to 1.5 mm²) or 2× (0.75 to 2.5 mm²) solid or stranded wire — strip length follows standard Siemens practice.

Frequently asked questions

How do I get current pricing and availability for 3RV2411-1KA15?

Submit an RFQ through this listing. We source through independent distribution channels and confirm both price and availability at quote time — no automated stock figures here, just a real quote against your order quantity.

Will 3RV2411-1KA15 drop into a panel spec'd around 3RV1011-1HA10?

The 3RV2411-1KA15 uses the same 45 mm width and screw/snap-on 35 mm DIN rail mounting as the SIRIUS 3RV1 family, so it fits the same rail footprint. Terminal sizes and clearance requirements are comparable, but verify the transformer protection-specific trip curve matches your load — the 3RV2411 is designed for transformer protection, while the 3RV1011 is a general-purpose motor-protective breaker.

What compliance documentation does Siemens provide for 3RV2411-1KA15?

Siemens SIRIUS components typically carry CE, UL, CSA, and CCC certifications, with RoHS and REACH declarations available through the standard documentation portal. Specific certificate numbers for this order code are confirmed at order time against the current production batch.
