The Siemens 6ES7141-5AH00-0BL0 is an IO-Link master block for distributed I/O, rated for direct machine mounting IP65/67. It carries 16 digital inputs and 8 digital outputs, supplied from the IO-Link master's IUs+. Temperature range covers -30 to 55 °C, so it handles unheated enclosures or outdoor cabinets without derating. Cycle time minimum 2.5 ms suits fast sensor readouts.
Input & output detail
On the input side, signal thresholds are -30 to +5 V for logic 0, +11 to +30 V for logic 1. Typical input current at signal 1 is 3 mA. The 16 inputs share a 0.7 A total current limit drawn from the IO-Link master supply. Short-circuit protection is per module, electronic. Sensor supply to M is also short-circuit protected module by module. Reverse polarity on the encoder power outputs won't destroy the module. Diagnostic alarm is parameterizable. Channel status displayed via green LED; module diagnostics via green/red LED.
