6ES7193-CE00-AA0
Siemens
Ref. price$4.89
Lead time on requestGet quote
SIMATIC S7 PLC
1052 variants · Siemens
About the SIMATIC S7 PLC
The Siemens SIMATIC S7 PLC series groups 1052 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by depth, height and width, so you can match the exact depth your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current SIMATIC S7 PLC variants and discontinued ones from a single page.
Select a variant by
- Depth
- 35 mm · 52 mm · 55 mm · 75 mm · 181 mm
- Height
- 81 mm · 100 mm · 110 mm · 130 mm · 265 mm
- Width
- 15 mm · 45 mm · 70 mm · 87 mm; Width module 60 mm · 120 mm
- Measurement principle
- Differential · Integrating
- Conversion time per channel
- 4.7/19/22/102 ms · 20.625 ms; 20.625 ms at 50 Hz; 17.25 ms at 60 Hz · 65 ms; 55 / 65 ms · 67 ms · 110 ms; 110 / 130 ms
- Temp operating max
- 24 °C · 55 °C
- Temp operating min
- 3 °C · 15 °C · 25 °C
- I/O channels
- 2 · 4
Variant comparison
| Parameter | 6ES7144-1FB31-0XB0 | 6ES7144-4FF00-0AB0 | 6ES7223-1PL32-0XB0 | 6ES7223-1QH32-0XB0 | 6ES7144-4JF00-0AB0 | 6ES7144-4PF00-0AB0 |
|---|---|---|---|---|---|---|
| Depth | 55 mm | 35 mm | 75 mm | 75 mm | 35 mm | 35 mm |
| Height | 110 mm | 130 mm | 100 mm | 100 mm | 130 mm | 130 mm |
| Width | 87 mm; Width module 60 mm | 45 mm | 70 mm | 45 mm | 45 mm | 45 mm |
| Measurement principle | Integrating | Integrating | — | — | Integrating | Integrating |
| Conversion time per channel | — | 67 ms | — | — | 20.625 ms; 20.625 ms at 50 Hz; 17.25 ms at 60 Hz | 4.7/19/22/102 ms |
| Temp operating max | — | — | 55 °C | 55 °C | — | — |
| Temp operating min | — | — | 3 °C | 3 °C | — | — |
| I/O channels | 2 | 4 | — | — | — | — |
Request a quote on any SIMATIC S7 PLC part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
